Connector Applications

Driven by Quality and Innovation



Whether in the interior or in highly loaded areas as in the engine compartment and at the axle cabling – our portfolio includes first-class connectors for all applications. Thereby, our products are as diverse as their areas of application: They can be used for sealed or open systems. Furthermore, they are available as miniaturized or overmolded variants.



Our connectors are absolutely reliable. Depending on the area of application they are waterproof and vibration- and temperature-resistant. They guarantee maximum performance even under highest thermal and dynamic loads.

Connected by Passion

Our entire product range meets international automotive standards. In close collaboration with renowned OEMs we developed a standardized portfolio of connector and pin housings. We offer them in various designs regarding pole numbers, codings and interfaces.

Moreover, we design customized solutions exactly according to customer requests. This is our core competence, which we pursue with passion! Together with our customers we are shaping the sustainable mobility of tomorrow.



SealStar

Our connectors are characterized by high performance and durability. They are available in various designs.



The SealStar-Family was designed by Hirschmann Automotive in close collaboration with renowned OEMs and their system manufacturers. The plug connector systems are compact, robust as well as water-tight and stand out due to excellent performance characteristics. Besides the water-tightness according to LV 214, the products impress with their high temperature and vibration resistance.

The webshop at shop.hirschmann-automotive.com offers a standard product range of SealStar plug connectors. Technical data and specifications, drawings as well as 3D models are also available for download there. Samples can be requested free of charge at any time.




SealStar

0.63 SealStar

The housings have a variety of positive features. They withstand extreme conditions.

Read more

SealStar

1.2 SealStar Female

Our connectors are compact and robust. Their features guarantee optimum performance.

Read more

SealStar

1.2 SealStar Male

Our connectors are compact and robust. Their features guarantee optimum performance.

Read more

SealStar

1.2 SealStar Service Disconnect

The Service Disconnect Connector ensures easy disconnection to prevent unintentional activations during maintenance.

Read more

SealStar

2.8 SealStar SLK

Our connectors are miniaturized and watertight. They meet all requirements of the automotive industry.

Read more

SealStar

2.8 SealStar

We have refined our connectors. More than ever the new design stands for lightweight construction and efficiency.

Read more

SealStar

2.8 SealStar Service Disconnect

The Service Disconnect Connector ensures easy disconnection to prevent unintentional activations during maintenance.

Read more

SealStar

SealStar Hybrid Connector

Our Hybrid Connectors are designed for versatility. It supports multiple blade sizes within one connector and combines innovation with reliability.

Read more

SealStar

SealStar PinHeader

The development of our SealStar PinHeader has laid the foundation for a compact, robust and watertight generation of PinHeaders, without compromising on performance.

Read more

SealStar HMK

The SealStar HMK product range shows all of its strengths when everything is vibrating in the engine compartment.



Our patented HMK product range offers various high-quality features. It impresses, for example, with maximum vibration resistance and tightness. On top of that, the high-performance engine contact systems function reliably even at extreme temperatures.

The products are offered with an AK receptacle and can be customized automatically. Thanks to the patented insertion process, the effort in manual assemblage is small, while the normal contact force is reliable and high.


SealStar HMK

1.2 SealStar HMK

Our patented high-performance engine contact system withstands highest loads.

Read more

SealStar HMK

2.8 SealStar HMK

In addition to the SealStar qualities, our patented systems have several other positive features.

Read more

EasyConn

The connector housings have a particular compact design. Various contact systems can be used there.



The EasyConn housing family is available with different pole numbers – in male and female versions. In particular, it is characterized by its compact design, the various color and mechanical coding options as well as the comfortable and secure latching function. The design layout is compliant with VDA AK guidelines. High levels of thermal stress do not pose a problem for the EasyConn Family.




EasyConn

2.8 EasyConn

Our versatile EasyConn housing family is sure to meet your requirements as well.

Read more

Caps & Covers

Protective Caps for Connectors



Dirt or water can harm connectors. Hence, we developed special protective caps that are compatible with a selection of our SealStar and SealStar HMK connectors.

The caps are easy to assemble. Their ergonomic design ensures optimum power transmission during the plug-in process. The material is suitable for high-pressure as well as steam cleaning and withstands, among other things, high thermal loads.


Caps & Covers

Protective Caps

Small components with a big impact - our protective caps stabilize our connectors and protect them from external influences.

Read more
